描述
High-Speed IC Handler Type: High-Speed IC Handler Power Input 200–240 VAC (single phase), 50/60 Hz, 6 kVA max Air Requirement 0.49 MPa (≈ 5 kgf/cm²) Main Motors AC servo axes (400 W × 4, 200 W × 2) + Stepper Z-axis (2 W) Tray Handling Robot 100 W AC servo motor Tray Lift/Unload 6 W induction motor Dimensions 1700 (W) × 1500 (D) × 1760 (H) mm Weight Approx. 920 kg Build Date Dec 2005 (label “12.05”) Control Electronics Omron & SMC modules, servo amplifiers, and PLC logic network Axes Observed Main I/O, Test arm (X–Y–Z–U), Tray robot, Shuttle arm —all servo driven Typical Throughput ≈ 4 000 – 7 000 devices/hour (depending on package type and tester) System Description: Handler type: Tray-based high-speed sorter/loader for ICs, QFNs, BGAs, or similar components. Operation: Feeds trays to the test site. Picks up individual devices with vacuum end-effectors. Loads them into sockets on a tester interface or prober. Sorts parts by bin (pass/fail/parametric grades) back into trays. "Control system: Industrial PLC and Omron motion controllers with coordinated multi-axis servos (visible in your wiring photo). Mechanics: Precision linear stages, pneumatic actuators, and vacuum-based pick tools for high-accuracy alignment. "Integration: Commonly mated with testers from Advantest, Teradyne, or Chroma for functional and parametric IC testing. Clean wiring and intact servo modules, no dust corrosion. All original Seiko Epson harnesses and linear stages in place. With roughly 1-ton build weight, eight controlled axes, and precision tray-handling, it remains a valuable platform for labs or secondary fabs handling medium-volume IC packaging or repurposing for robotic-pick automation.配置
無配置OEM 代工型號說明
Handler文檔
無文檔
類別
Final Test
上次驗證: 18 天前
關鍵商品詳情
條件:
Used
作業狀態:
未知
產品編號:
150378
晶圓尺寸:
未知
年份:
2005
Logistics Support
Available
Transaction Insured by Moov
Available
Refurbishment Services
Available
類似上架商品
查看全部
SEIKO / EPSON
